  Mining & Aggregate.

OVERVIEW
EQUIPMENT
CLIENTS


CLIENTS

A BRIEF EXCERPT OF OUR CLIENT LIST FOR MINING & AGGREGATE EQUIPMENT

Alouette Aluminum
Century Mining Corporation
Cliffs Natural Resources
DRA Americas
Gypsum Technologies Inc.
Holcim Inc.
Labrador Iron Mines
Lafarge Canada Inc.
McCoy Equipment
Nunavik Nickel
San Gold Corporation
St. Mary's Cement
Tata Steel / New Millennium Iron

ASSOCIATIONS

TS MANUFACTURING BELONGS TO AND SUPPORTS ASSOCIATIONS AND GROUPS IN THE MINING & AGGREGATE INDUSTRIES.

CIM.org

CAMESE.org


OVERVIEW
A BRIEF LISTING OF THE EQUIPMENT WE MANUFACTURE

If what you're looking for is not listed here, please contact our sales people for more information. We can handle individual machines to full 'Turn Key' projects, manufacturing most every piece of equipment ourselves. Download a copy of our Mining Brochure.

Belt Conveyors
Chain Conveyors
Gallery Systems
Ship Loaders
Link Conveyors
Radial Stackers
Reclaim Systems
Underground Conveyors

Flexi-Wall Belts
Tube Conveyors
Belt Feeders
Screw Conveyors
Screw Dischargers
Feeders
Handrails
Safety Guarding

Multi-Chain Conveyors
Drag Chain Systems
Chuting
Loading Hoppers
Head End Discharges
Grizzlies
Sub Structures
Catwalks

CONVEYING SYSTEMS TO SUIT THE REQUIREMENTS OF THE MOST CHALLENGING PROJECT

TS Engineers work to your exacting specifications.

TS Manufacturing can work with you or your engineers to ensure your system will meet the most exacting specifications. Whether the project calls for Troughed Idler Belt Conveyors, Gallery Conveyors, Stringer Conveyors, Underground Conveying, Tubular Conveying or even Stacking Systems, we have the Conveying solution to suit your needs. Talk to us about our Standard designed Spans available in any CEMA Standard(s) or ask us to assist with a more custom solution. Our in-house engineering team has an accomplished track record of working with consultants to ensure that the finished product exceeds expectations.

TS designs, manufactures and installs mining & aggregate equipment.We've been designing, manufacturing and installing mining and aggregate equipment for almost 40 years. TS Manufacturing has been designing, manufacturing and installing quality bulk material handling systems for mining, aggregate, quarry, cement and many other industries for nearly 40 years.

Our experienced engineering department utilizes the latest in CAD design software and is capable of working in 2D or 3D with nearly any file format. Our Project Managers have experience working directly with customers as well as working with Consulting Engineering firms. Our Project Managers oversee everything from equipment consultation to the entire lifecycle of complete projects. We have equipment installed on 6 continents.

We will design and manufacture your system, deliver it to your site, on time and on budget, anywhere in the world. Our Systems Application Personnel are ready to quote using our standard high quality components or work to your system and component specifications, to reduce your maintenance, inventory and operational costs.

EQUIPMENT
TS Belt Conveyors   BELT CONVEYORS

Whether your project calls for Idlers or Slider Bed Conveyors, Gallery Conveyors, Underground Conveyors, Trippers, Shuttles or Stacking Systems, TS has the conveying solution to suit your application. TS will engineer, design, detail and certify your customized belt conveyor anywhere from 18" to 96" belt widths. We also have standard designed truss spans available in CEMA standardized sizes.

We supply Belt Conveyor needs from the pit to the ship, where the material handled can range from primary crushed ore in the mine to powder concentrate in your mill.



TS Belt Feeder   BELT FEEDERS

TS Feeders are heavy-duty designs, built to handle the harshest mine environments. They include engineered class pulleys with power or hydraulic assisted take-ups. Belts are very high tensile strength with thick, abrasion resistant covers. They are usually provided with a hopper or diverging loading trough to suit the customer's ore bin.




TS Chain & Bar Conveyors   CHAIN / BAR FEEDER CONVEYORS

Heavy duty chain and square bar flights help keep our Chain Conveyors running in punishing environments. Environments like open pit crusher feeds. Extra thick wear liners protect our chain ways and sidewalls from wear. Options such as chain curtains and Grizzlies can be added.



TS Chuting   CHUTING

Chute work can be included with our conveyors or supplied separately. TS Chutes are heavy duty and re-inforced as necessary with wear liners, rock boxes and diverter gates. Because our head chutes are designed with the calculated material trajectory in mind, we can fine tune the shape to help center the load.

Different plugged chute switches are used depending on the customer's preference and the material being transferred. Movable rock boxes are designed with wheels, rails and actuators to allow easy removal and positioning to direct material flow.



  FLEXI-WALL BELT CONVEYORS

Using Corrugated Sidewall Belting, TS makes high angle conveyors in various configurations to suit the layout of your plant. They're especially effective in constrained-space locations, and reduce the number of conveying equipment and transfer points. Common configurations include straight, high incline, "L" or "S" shapes, and can be run at any angle - including vertically.



TS Gallery Conveyor   GALLERY SYSTEMS

For protecting your material and personnel from the weather, we offer our conveyors with Galleries containing the belt and walkways in full or partially weather tight enclosures. These can be optionally completed with:
• thermal insulation
• lighting
• windows
• sealed floors

We can also offer Galleries in tubular steel designs. TS has designed and manufactured a wide variety of Gallery systems - some up to 3000' long. We have the fabrication capacity to handle the extremely large conveying projects. Our Galleries and Trusses can also be designed for tandem use with pipe racks and walkways.



TS Grizzly Bars   GRIZZLIES

Heavy duty steel bars can cover your hopper or reclaim pit - with the spacing between the bars to suit the desired material size. We can build a Grizzly to withstand your largest uncrushed ore sizes, while simultaneously handling vehicle traffic like coal scrapers and front-end loaders.



TS Handrails   HANDRAILS

All of our Handrails are designed to meet safety regulations and customer standards. We provide round-pipe style, square tube or angle - depending on your preference. Features such as heavy-schedule pipe posts, galvanizing, safety yellow epoxy coating, and self-closing safety gates, are also offered.



TS Link Conveyor   LINK CONVEYORS

These interconnecting movable Belt Conveyors are used in series to feed stackers or ship loaders. They can have the same features as our other Belt Conveyors, but can be placed in almost any configuration in an open pit, storage area or wharf. Normally they are built with legs with sliders at the bottom, but optionally they can be provided with wheels.



TS Loading Hoppers   LOADING HOPPERS

Hoppers are located above the Belt Conveyor and allow the belt to be fed by another conveyor or a front-end loader. Custom options such as special liners and deflectors are used to improve load centering to better suit the needs of the material being conveyed.



TS Overland Belt Conveyors   OVERLAND BELT CONVEYORS

With its partners, TS can provide Overland Conveyors for any terrain – through mountains, valleys, buildings and even northern muskeg. We will gladly provide comparative, budgetary pricing for trucking - to show how an Overland Conveyor will save you money in the long term.



TS Platforms and Catwalks   PLATFORMS AND CATWALKS

Supplied with our other systems, or as a stand-alone project, TS makes access and egress solutions for your equipment. These systems include logical access for maintenance, and options such as serrated bars, hot dip galvanizing and aperture banding. Our global experience has made us familiar with all the codes and regulations necessary for your design.



TS Radial Stacker   RADIAL STACKERS

Radial Stackers are an excellent solution for most stockpiling needs. Whether it's ore, coal, aggregate, limestone, pellets, scrap metal, or almost any bulk material, TS builds heavy duty Radial Stackers that suit your needs and reduce storage costs.

They can be customized with any options you require. Options like:
• 24-60" belt width
• road-portable or site-stationary mobility
• weather covers
• power travel with remote control
• power raise
• walkways at any width



TS Safety Guarding   SAFETY GUARDING

TS Conveyors and machinery are guarded for the safety of your personnel. We are familiar with all the current safety standards and government regulations regarding machinery guards. We also understand that equipment needs to be service accessible, so we provide practical guarding systems that facilitate this.

We can upgrade guards on your existing equipment or incorporate your own guidelines into our customized guarding. Features such as access doors and special mesh sizes can also be chosen.



TS Screw Conveyor   SCREW CONVEYORS

TS Screw Conveyors are used in a variety of industries - power plants, mineral processing, chemicals, and more. TS screws are built to CEMA standards, but are custom designed to client specifications as well. Features such as slide gates, mixing, abrasion resistance, stainless steel, spark-resistance, etc. can be incorporated into your application. Troughs and liners are selected and designed to suit the material conveyed for maximum life of the trough.



TS Screw Feeders & Dischargers   SCREW FEEDERS / DISCHARGERS

In applications such as pulverized coal, Screw Conveyor Feeders and Bin Dischargers are ideal. They meter the material and provide a good air seal to the bin above. In addition, stainless steel flights can be used to prevent sparking.



TS Ship Loader   SHIP LOADERS

Using Belt Conveyors and Stackers, TS can design a Ship Loading solution that meets your site-specific requirements. Our designs optimize the number of loading moves, tidal changes, and allowable weight on the dock.



TS Sub-Structures   SUB-STRUCTURES AND HEAVY FABRICATIONS

TS Manufacturing designs and assembles sub-structures to accommodate mining equipment like machinery bases, towers and conveyor support bents. Other fabrications include:
• Turntables
• Mounting brackets
• Heavy vehicle ramps
• Plate work



TS Underground Conveyors   UNDERGROUND CONVEYORS

Either floor-supported or ceiling-hung, our modular Underground Conveyor sections can be made to match your existing system. TS Underground Conveyors are made to install simply and quickly using either fixed frame idlers or garland idlers. Any variety of MSHA and CSA fire resistant belting can be provided.
